Highlights

Geodex G60Pro+ GNSS Receiver is an innovative, high-performance solution designed to boost productivity in the field. Equipped with an AR Visual Stakeout Camera, it transforms your surveying experience with cutting-edge technology.

  • Complete Built-In Connectivity: UHF, Lora Radio, 4G network, Bluetooth and WIFI

  • Supports multiple operational modes—Base station, Rover, and Static GPS

  • IMU Tilt Compensation: Increases point measurement & point stakeout efficiency by 20%

  • AR Visual Camera Enhanced Stakeout Productivity by at least 30%

  • Lightweight & Portable

Geodex GPS device with digital interface, featuring geospatial technology. Background includes digital grid map and location icons, indicating navigation and mapping capabilities.

Main Features

IMU Tilt Compensation: Increases point measurement efficiency by 20%, enabling faster and more accurate data collection.

Promotional graphic for IMU Tilt Survey Technology, highlighting features: no calibration needed, stable data collection, wide tilt capability up to 60 degrees with under 2cm error, and 30% boosted efficiency. Includes two survey poles at different angles.
Illustration of a long-range transmission with GeoMask II protocol over a city map. Includes features such as extended range, energy efficiency, interference resistance, reliable performance, and remote operation. Shows a satellite dish and signal waves extending 10 km.

Long-range UHF radio Transmission Extended Range: Transmits up to 10km with UHF radio GeoMask II protocol

GeodeX P9III device with screen and keypad on blue background
GNSS surveying equipment with two receivers on tripods, one with a handheld controller.

Versatile Work Modes:

Supports multiple operational modes

  • Base station

  • Rover

  • Static GPS

providing flexible solutions for a wide range of surveying needs.

Main Features

  • Waterproof IP67 Rating

    Waterproof IP67 Rating

    Features a fully sealed design, offering IP67 waterproof protection, ensuring reliable performance even dropped at a depths of up to 1 meter underwater for 15min.

    Send Inquiry
  • AR Visual Stakeout

    AR Visual Stakeout

    The AR Visual Camera boosts stakeout productivity by at least 30%, offering visual guidance for more efficient workflows.

    Send Inquiry

Main Features

  • Compact Design

    Compact Design

    Lightweight & Portable: The compact design ensures easy portability, enhancing comfort on the job site and reducing operator fatigue, no matter the task or location.

    Send Inquiry
  • Fast Charging

    Super Fast Charging

    Quick Full Charge: Fully charges in just 3 hours using the latest fast-charging technology.

    Reliable Power: Quickly recharge to ensure at least 15 hours smooth and continuous operation.

    Send Inquiry

Application Cases

Illustration with icons representing topographic surveying, agricultural field mapping, and pipeline surveying. The topographic surveying icon features a globe with arrows, agricultural field mapping includes a globe with leaves, and pipeline surveying shows a pipe with an angle measurement.
Surveying equipment with GNSS receivers and data collector on tripod and rod.

Benefits & Performances

  • Satellites Tracking: GPS: L1C/A, L1C,L1P,L2C,L2P, L2CL5

    GLONASS: L1, L2, L3

    BDS: B1I, B2I, B3I, B1C, B2a, B2b

    Galileo: E1, E5a, E5b, E6

    QZSS: L1, L2, L5, L6

    SBAS: L1, L5; IndiaIRNSS: L5

  • Versatile Work Modes: Supports multiple operational modes—Base station, Rover, Ntrip Rover and Static GPS, providing flexible solutions for a wide range of surveying needs. When connected to a GNSS RTK network via Geodex SurDex field software, it excels as a highly efficient NTRIP rover.

  • Built-In Connectivity: Features a complete data link system, including UHF, Lora Radio, 4G network, Bluetooth and WIFI, ensuring seamless communication in any environment.

  • Weighing just 0.85 kg, the G60Pro+'s compact magnesium alloy design ensures easy portability and operation, reducing operator fatigue and enhancing survey comfort during fieldwork.

  • Boost point measurement efficiency by 20% and stakeout speed by 50% with the G60Pro+. Its automatic compensation for up to 60° pole tilt removes the need for precise pole leveling, &provide visual guidance for point stakeout, enhancing field productivity.

  • With an IP67 rating, the G60Pro+ is fully dustproof and waterproof, delivering reliable performance in harsh environments. Its rugged design resists shock and vibration, making it ideal for demanding fieldwork.

  • High-Capacity Battery: Features a 3.7V 3400×4mAh lithium cell for long usage.

    Extended Operation: Provides up to 15 hours of continuous operation on a single charge.

    All-Day Reliability: Designed to support lengthy fieldwork without interruptions.
